DS-2DF8436IX-AELW

DS-2DF8436IX-AELW

37.380.000đ 66.750.000đ -43%
HIKVISION

4MP 36× Network IR Speed Dome
• 1/1.8” HD CMOS sensor
• Up to 2560 × 1440 resolution
• 36x Optical Zoom
• Min. Illumination:
  Color: 0.002 Lux @(F1.5, AGC ON)
  B/W: 0.0002 Lux @(F1.5, AGC ON)
  0 Lux with IR
• Smart Tracking
• Smart Detection
• 200m IR distance
• Optional wiper(-W)
• Hi-PoE / 24VAC power supply
• Support H.265+/H.265 video compression
• Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
• IP67, IK10

Còn hàng
1

Camera 2MP IR Speed Dome, Hồng ngoại 200m (Tích hợp tính năng thông minh)

  • Cảm biến CMOS 4MP, 1/1.9’’
  • Chuẩn nén  H.265+/H.265/H.264+/H.264
  • Siêu nhạy sáng Darkfighter, Color: 0.005 lux/F1.5, B/W: 0.0005 lux/F1.5
  • Cân bằng sáng Digital WDR
  • Góc quay: 360°; Góc quét: -20°~90°(tự động lật), tốc độ quay Pan: 0.1°~210°/s, tốc độ quét: 0.1°~150°/s
  • Zoom Quang: 36x
  • Focus: 5.7-205.2 mm
  • Tính năng theo dõi thông minh, phát hiện thông minh
  • Chống sương mù
  • Lấy nét tức thì
  • Hồng ngoại 200m IR
  • Tiêu chuẩn chống bụi, nước IP66
  • Chống đập phá IK10
  • Hỗ trợ nguồn Hi-PoE và 24VAC.


DS-2DF8436IX-AEL(W)

Camera

Image Sensor:



1/1.8" progressive scan CMOS

Effective Pixels:



2560(H)×1440(V)

Signal System:



PAL/NTSC

Minimum Illumination:



Color: 0.002 Lux @(F1.5, AGC ON)
B/W: 0.0002 Lux @(F1.5, AGC ON)
0 Lux with IR

AGC:



Auto/Manual

BLC:



ON/OFF

HLC:



Support

Smart defog:



Support

WDR:



120dB

Shutter Time:



50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s

Day& Night:



ICR

Digital Zoom:



16X

Privacy Masking:



24 privacy masks programmable

Auto Focus:



Auto / Semi-automatic / Manual

Lens

Focal Length:



5.7 mm to 205.2 mm, 36× Optical

Zoom Speed:



Approx. 4.4s (optical lens, wide-tele)

Angle of View:



Horizontal field of view: 51.1° to 1.7° (wide-tele)
Vertical field of view: 31.3° to 1.0° (wide-tele)
Diagonal field of view: 58.0° to 2.0° (wide-tele)

Minimum Working Distance:



10-1500mm(Wide-Tele)

Aperture Range:



F1.5~F4.5

Pan & Tilt

Pan Range:



360°endless

Pan Speed:



Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s

Tilt Range:



-20°~90°(Auto Flip)

Tilt Speed:



Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s

Proportional Zoom:



Rotation speed can be adjusted automatically according to zoom multiples

Number of Preset:



300

Patrol:



8 patrols, up to 32 presets per patrol

Pattern:



4 patterns, with the recording time not less than 10 minutes per pattern

Power-off Memory:



Support

Park Action:



Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan

PTZ Position Display:



ON/OFF

Smart-tracking:



Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger

Wiper:



Optional

Infrared

IR irradiation distance:



200m

IR irradiation angle:



Adjustable by zoom

Alarm

Alarm Input:



7 Inputs

Alarm Output:



2

Alarm Actions:



Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel

Network

Ethernet:



10Base -T, /100Base-TX, RJ45 Connector

Main Stream:



50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub Stream:



50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)

Third Stream:



50Hz: 25fps(704×576, 640×480, 352×288);
60Hz: 30fps(704×480, 640×480, 352×240)

Video Compression:



Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG

ROI encoding:



Support

Audio Compression:



G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM

Audio Mode:



OFF/Audio input/Audio output

No. of Simultaneous Users:



Up to 20 users

Three-Stream:



Support

Mini SD Card:



Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB

Security Measures:



User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering

Client GUI

Camera Control:



Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode

Date & Time Display:



Time: Week: Date, 6 formats on the Client

Client:



Support iVMS-4200

Web Browser:



IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 +

General

RS-485 Protocols:



HIKVISION, Pelco-P, Pelco-D, self-adaptive

Power Supply:



24 VAC & Hi-PoE

Power Consumption:



24 VAC (Max. 60 W)
Hi-PoE (Max. 50 W)

Working Temperature/Humidity:



-40°C ~ 65°C (-40°F ~ 149°F)

Protection Level:



IP67 Standard, IK10 (only supported by camera without wiper), TVS 6,000V Lightning Protection, Surge Protection and Voltage Transient Protection

Dimensions:



Φ 266.6 mm × 410 mm (Φ 10.50" × 16.14")

Weight (approx.):



8kg (approx.17.64lb)



•    Sản phẩm nhập khẩu chính hãng HIKVISION
•    Cam kết 1 đổi 1 nếu sản phẩm có vấn đề về chất lượng hoặc do lỗi của nhà sản xuất.
•    Bảo hành trong suốt 24 tháng.
