DS-2DE4225IW-DE

DS-2DE4225IW-DE

7.980.000đ 14.250.000đ -43%
HIKVISION

2MP 25X Network IR PTZ Camera
• 1/2.8" progressive scan CMOS
• Up to 1920 × 1080@30fps resolution
• Min. illumination:
    Color: 0.005 Lux @(F1.6, AGC ON)
    B/W: 0.001 Lux @(F1.6, AGC ON)
• 0 Lux with IR
• 25× optical zoom, 16× digital zoom
• WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
• Up to 100 m IR distance
• 12 VDC & PoE+ (802.3 at, class4)
• Support H.265+/H.265 video compression

Còn hàng
1

Camera IP Speed Dome quay quét 2MP

  • Độ phân giải 2MP
  • Cảm biến CMOS 1/2.8"
  • Hỗ trợ chuẩn nén H.265+/H.265/H.264+/H.264
  • Tính năng giảm nhiễu số 3D DNR
  • Cân bằng sáng True WDR
  • Tính năng siêu nhạy sáng DarkFighter
  • Có màu tại: 0.005lux/F1.6, Đen trắng tại: 0.001lux/F1.6
  • Zoom quang: 25x, Zoom số: 16X
  • Hồng ngoại 100m
  • Độ phân giải 1920*1080:30fps
  • Tốc độ quay: 0.1° -80°/s, Tốc độ quét: 0.1° -80°/s
  • Hỗ trợ PoE+ & 12VDC
  • Tính năng phát hiện thông minh.


DS-2DE4225IW-DE

Camera

Image Sensor:



1/2.8" HD progressive scan CMOS

Effective Pixels:



1920(H)x1080(V)

Signal System:



PAL/NTSC

Minimum Illumination:



Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001Lux @(F1.6, AGC ON)
0 Lux with IR

White Balance:



Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp

AGC:



Auto/Manual

BLC:



ON/OFF

HLC:



Support

Smart defog:



Support

WDR:



120dB

Shutter Time:



1-1/10,000s

Day& Night:



ICR

Digital Zoom:



16X

Privacy Masking:



24 privacy masks programmable; optional multiple colors and mosaics

Auto Focus:



Auto / Semi-automatic / Manual

Lens

Focal Length:



4.8 mm to 120 mm, 25× optical zoom

Zoom Speed:



Approx. 3.6 s (optical lens, wide-tele)

Angle of View:



Horizontal field of view: 57.6° to 2.5° (Wide-Tele)
Vertical field of view: 34.4° to 1.4° (Wide-Tele)
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)

Minimum Working Distance:



10-1,500mm(Wide-Tele)

Aperture Range:



F1.6 to F3.5

Pan & Tilt

Pan Range:



360°endless

Pan Speed:



Configurable, from 0.1°/s to 80°/s,
Preset speed: 80°/s

Tilt Range:



-15°-90° (Auto Flip )

Tilt Speed:



Configurable, from 0.1°/s to 80°/s,
Preset speed: 80°/s

Proportional Zoom:



Rotation speed can be adjusted automatically according to zoom multiples

Number of Preset:



300

Patrol:



8 patrols, up to 32 presets per patrol

Pattern:



4 pattern scans, record time over 10 minutes for each scan

Power-off Memory:



Support

Park Action:



Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

PTZ Position Display:



ON/OFF

Infrared

IR irradiation distance:



100m

IR irradiation angle:



Adjustable by zoom

Input & Output

Audio Input:



1-ch audio input

Audio Output:



1-ch audio output

Network

Ethernet:



10Base -T, /100Base-TX, RJ45 Connector

Max.Image Resolution:



1920×1080

Main Stream:



50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)

Sub Stream:



50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)

Third Stream:



50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)
60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)

Video Compression:



Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG

ROI encoding:



Support 4 areas with adjustable levels

Audio Compression:



G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM

Audio Mode:



OFF/Audio input/Audio output

Protocols:



IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour

No. of Simultaneous Users:



Up to 20 users

Three-Stream:



Support

Mini SD Card:



Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB

User/Host Level:



Up to 32 users, 3 levels: Administrator, Operator and User

Security Measures:



User authentication (ID and PW), host authentication (MAC address)

Hik-Connect:



Support

Client GUI

Client:



iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

Web Browser:



IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51

General

Menu Language:



English

Power Supply:



12VDC, PoE+

Power Consumption:



Max.: 18 W (Max. 7 W for IR)

Working Temperature/Humidity:



-30 ℃-65℃(-22℉-149℉)(outdoor)
90% or less

Protection Level:



IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection

Material:



ADC 12, PC, PC+10%GF

Dimensions:



Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42")

Weight (approx.):



Approx. 2 kg (4.41 lb)



•    Sản phẩm nhập khẩu chính hãng HIKVISION
•    Cam kết 1 đổi 1 nếu sản phẩm có vấn đề về chất lượng hoặc do lỗi của nhà sản xuất.
•    Bảo hành trong suốt 24 tháng.
